Specifications
Image Sensor: 1/2.8″ progressive scan CMOS; Max. Resolution: 1920 × 1080; Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux@(F1.6, AGC ON), 0 Lux with IR; Shutter Speed: 1/1 s to 1/30000 s; Day & Night: IR cut filter; Zoom: 32x optical, 16x digital; Slow Shutter: Yes; Focal Length: 4.8 mm to 153 mm; FOV: Horizontal field of view: 55° to 1.7°, vertical field of view: 33° to 1.0°, diagonal field of view: 62.4° to 1.9°; Focus: Auto, semi-auto, manual; Aperture: Max. F1.6; Zoom Speed: Approx. 4.8 s; Supplement Light Type: IR; Supplement Light Range: IR Distance: up to 200 m; Movement Range (Pan): 360°; Movement Range (Tilt): -15° to 90° (auto flip); Pan Speed: Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s; Tilt Speed: Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s; Proportional Pan: Yes; Presets: 300; Preset Freezing: Yes; Patrol Scan: 8 patrols, up to 32 presets for each patrol; Pattern Scan: 4 pattern scans; Park Action: Preset, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan; 3D Positioning: Yes; PTZ Status Display: Yes; Scheduled Task: Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output; Power-off Memory: Yes; Main Stream: 50 Hz: 50 fps (1920 × 1080, 1280 × 960, 1280 × 720),
60 Hz: 60 fps (1920 × 1080, 1280 × 960, 1280 × 720); Sub-Stream: 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240); Third Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240); Video Compression: Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG; Video Bit Rate: 32 kbps to 16384 kbps; H.264 Type: Baseline Profile/Main Profile/High Profile; H.265 Type: Main Profile; Scalable Video Coding (SVC): H.264 and H.265 encoding; Region of Interest (ROI): 8 fixed regions for each stream; Audio Compression: G.711,G.722.1,G.726,MP2L2,PCM,MP3,AAC-LC; Audio Bit Rate: 64 Kbps (G.711),16 Kbps (G.722.1),16 Kbps (G.726),32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3); Audio Sampling Rate: MP2L2: 16kHz, 32kHz, 48kHz,AAC-LC: 16kHz, 32kHz, 48kHz,PCM: 8kHz, 16kHz, 32kHz, 48kHz,MP3: 8kHz, 16kHz, 32kHz, 48kHz; Environment Noise Filtering: Yes; Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour; Simultaneous Live View: Up to 20 channels; API: ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP; User/Host: Up to 32 users, 3 user levels: administrator, operator, and user; Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address); Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR); Client: iVMS-4200, HikCentral Pro, Hik-Connect; Web Browser: IE11, Chrome 80+, Firefox 80+, Safari 13+, Edge 89+; Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser; Day/Night Switch: Day, Night, Auto, Schedule; Wide Dynamic Range (WDR): 120 dB; SNR: > 52 dB; Defog: Digital defog; Image Stabilization: EIS; Image Enhancement: BLC, HLC, 3D DNR; Privacy Mask: 24 programmable polygon privacy masks, mask color or mosaic configurable; Regional Focus: Yes; Regional Exposure: Yes; Ethernet Interface: 1 RJ45 10M/100M self-adaptive Ethernet port; On-board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB; Built-in Speaker: 1 built-in speaker with effective distance reaching max. 30 meters; Audio: 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω; Alarm: 2 inputs, 1 output; Reset: Yes; Basic Event: Motion detection, video tampering alarm, exception, alarm input and output; Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection; Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan); Smart Tracking: Manual tracking, auto-tracking; Face Capture: Detects up to 5 faces simultaneously.
Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face; Power: 36 VDC ± 25%, max. 42 W,
Hi-PoE; Dimension: Ø 220 mm × 363.3 mm (Ø 8.66″ × 13.91″); : Approx. 5 kg (11.03 lb.); Material: ADC12; Operating Condition: -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing); Demist: Yes; EMC: CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7),KC (KN 32: 2015, KN 35: 2015); Safety: UL (UL 62368-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 62368-1:2014+A11:2017);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (SANS IEC60950-1); Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006); Protection: IP67 (IEC 60529-2013),IK10 (IEC 62262:2002),TVS 6000 V lightning protection, surge protection and voltage transient protection
