High quality imaging with 2 MP resolution; Support Human and Vehicle Detection; Smart Hybrid Light: advanced technology with long range; Clear imaging against strong back light due to DWDR technology; Efficient H.265+ compression technology; Support on-board storage up to 512 GB (SD card slot); Built-in microphone for real-time audio security; 2.8 to 12 mm motorized varifocal lens for easy installation and monitoring; Water and dust resistant (IP67)
Available Models
DS-2CD2621G0-LIZSU(2.8-12mm)South Africa
Specifications
Image Sensor: 1/2.9″ Progressive Scan CMOS; Max. Resolution: 1920 × 1080; Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR; Shutter Time: 1/3 s to 1/100,000 s; Day & Night: IR cut filter; Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°; Lens Type: Varifocal lens, motorized lens, 2.8 to 12 mm; Focal Length & FOV: 2.8 to 12 mm, horizontal FOV 102.4° to 31.2°, vertical FOV 54.4° to 17.5°, diagonal FOV 121.8° to 35.7°; Lens Mount: Ø14; Iris Type: Fixed; Aperture: F1.6; DORI: D: 45.7 to 141.4 m, O: 18.1 to 56.1 m, R: 9.1 to 28.3 m, I: 4.6 to 14.1 m; Supplement Light Type: IR,White Light; Supplement Light Range: Up to 50 m; Smart Supplement Light: Yes; IR Wavelength: 850 nm; Main Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720); Sub-Stream: 50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360); Video Compression: Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG; Video Bit Rate: 32 Kbps to 16 Mbps; H.264 Type: Baseline Profile,Main Profile,High Profile; H.265 Type: Main Profile; Bit Rate Control: CBR,VBR; Scalable Video Coding (SVC): H.264 and H.265 encoding; Region of Interest (ROI): 1 fixed region for main stream; Audio Type: Mono sound; Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC; Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC); Audio Sampling Rate: 8 kHz/16 kHz; Environment Noise Filtering: Yes; Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP; Simultaneous Live View: Up to 6 channels; API: Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK; Security: Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address); User/Host: Up to 32 users
3 user levels: administrator, operator, and user; Client: iVMS-4200,Hik-Connect; Web Browser: Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+; Image Settings: Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser; Day/Night Switch: Day,Night,Auto,Schedule; Wide Dynamic Range (WDR): Digital WDR; SNR: ≥ 52 dB; Image Enhancement: BLC,HLC,3D DNR; Privacy Mask: 4 programmable polygon privacy masks; Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port; On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB; Built-in Microphone: Yes,1 built-in microphone; Audio: -S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
-S: 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium; Alarm: -S: 1 input, 1 output (max. 12 VDC, 30 mA); Reset Key: Yes; Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception; Linkage: Upload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning, (-S model) trigger alarm output; Power: 12 VDC ± 25%, 0.9 A, max. 11 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 12.9 W; Material: Metal & Plastic; Dimension: Ø105 mm × 252 mm (Ø4.13″ × 9.92″); Package Dimension: 315 mm × 137 mm × 141 mm (12.40″ × 5.39″ × 5.55″); : Approx. 570 g (1.3 lb.); With Package Weight: Approx. 900 g (2.0 lb.); Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing); Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing); Language: English; General Function: Heartbeat,mirror,password reset via email,password protection,anti-banding; EMC: CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7; Safety: UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1; Environment: CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006; Protection: IP67: IEC 60529-2013
