Hikvision 256-ch 4U 8K Super NVR DS-96256NI-H24R

Specifications

IP Video Input: 256-ch; Incoming Bandwidth: 1280 Mbps; Outgoing Bandwidth: 1280 Mbps; Incoming Bandwidth (RAID Mode): 1280Mbps; Outgoing Bandwidth (RAID mode): 1280 Mbps; HDMI 1 Output: 4K (4096 × 2160)/30 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; HDMI 2 Output: 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; VGA Output: 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; DP 1: 8K (7680 × 4320)/30Hz, 4K (4096×2160)/30 Hz, 4K (3840×2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; DP 2: 8K (7680 × 4320)/30Hz, 4K (4096×2160)/30 Hz, 4K (3840×2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; V-DP 1: 8K (7680 × 4320)/30Hz, 4K (4096×2160)/30 Hz, 4K (3840×2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; V-DP 2: 8K (7680 × 4320)/30Hz, 4K (4096×2160)/30 Hz, 4K (3840×2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; Video Output Mode: Provide 4 groups of video outputs. The video outputs in the same group provide simultaneous output, and the video outputs between each group provide independent output.
Group 1: HDMI 1/VGA/LCD
Group 2: HDMI 2
Group 3: DP 1/V-DP 1
Group 4: DP 2/V-DP 2
Note: After enabling DP 1/DP 2, V-DP 1/V-DP 2 would be unavailable.; Audio Output: 1-ch, 3.5mm; Two-Way Audio: 1-ch, 3.5mm; Decoding Format: H.265+/H.265/H.264+/H.264; Recording Resolution: 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF; Synchronous Playback: 16-ch; Decoding Capability: 3-ch@32 MP (30 fps)/3-ch@24 MP (30fps)/6-ch@16 MP (30fps)/12-ch@8 MP (30fps)/24-ch@4 MP (30fps)/48-ch@2 MP (30fps)
*: The length or width of camera resolution (each track) cannot exceed 4096 pixels.; Audio Compression: G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM; Network Interface: 4, RJ-45 10/100/1000/2500 Mbps self-adaptive Ethernet interface; Network Protocol: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS; Remote Connection: 256; RAID Type: RAID0, RAID1, RAID5, RAID6, RAID10; eSATA: 1 eSATA interface; SATA: 24 SATA interfaces supporting hot-plug; Capacity: Up to 20 TB for each HDD; Serial Interface: 1 RS-485 (full-duplex), 1 RS-232; Alarm In/Out: 16/8; USB Interface: Front panel: 2 × USB 2.0; Rear panel: 4 × USB 3.0; Power Supply: 100 to 240 VAC, 50 to 60 Hz, redundant power supply; Consumption: ≤ 75 W (without HDD); Working Temperature: 0 °C to + 50 °C (32 °F to 122 °F); Working Humidity: 10% to 90%; Chassis: 4U chassis; Dimension (W × D × H): 447 × 489 × 173 mm (17.6″ × 19.3″ × 6.8″); : ≤25 kg (without HDD, 55.1 lb.)
