Hikvision 305 m CAT6 UTP Network Cable (Solid Copper, 0.565 mm, CM) (DS-1LN6-UU)

Specifications

Core Color: 1 White- Blue /Blue 2 White-Orange /Orange,3 White-Green /Green 4 White- Brown /Brown,; Packing: Wooden Tray & Carton; Carton Dimension: Per request; Packing length: 305±1.5m; Rip-cord: Yes; Drain wire: No; Sheath Physical Properties: Before Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period (℃×hrs) 100℃×24h×10d,After Aging Tensile Strength(Mpa) ≥12.5, Elongation(%) ≥125,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks,; Electrical Characteristics (20℃): 1.0-250.0MHz Impedance ((Ω) 100±15,1.0-250.0MHz Delay Skew (ns/100m) ≤45,DC Resistance (Ω/100m) max 9.38,DC Conductor Resistance Unbalance (%) max 5.0,; Material: Solid-Bare Copper,Content 99.95%,; Nom.O.D.(mm): 0.565±0.005; Material: HDPE; Diameter: 1.02±0.05mm; Thickness: 0.55±0.05 mm; External O.D.: 6.2±0.4 mm; Surface: Clean,Frap,Satiation; Material: PVC(complies RoHS),CM; Color: Orange RAL2003; Letter height: 3.0±0.3mm; Color: Black; Print error & Space: ≤±0.5%，1m
