Hikvision 316L 8MP Underwater Vari-focal Bullet

Specifications

Image Sensor: 1/1.8″ Progressive Scan CMOS; Max. Resolution: 3840 × 2160; Min. Illumination: Color: 0.001 Lux @ (F1.4, AGC ON), B/W: 0 Lux with Light; Shutter Time: 1 s to 1/100,000 s; Focus: Auto,Semi-auto,Manual; Lens Type: Varifocal lens, motorized lens, 2.8 to 12 mm; Focal Length & FOV: 2.8 to 12 mm, horizontal FOV 70.7° to 30.0°, vertical FOV 39.0° to 16.9°, diagonal FOV 82.0° to 34.2°; Aperture: F1.4; DORI: Wide: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m
Tele: D: 220.0 m, O: 87.3 m, R: 44.0 m, I: 22.0 m; Supplement Light Type: White Light; Supplement Light Range: Turbidity (NTU) : 0 to 5, up to 1 m,
Turbidity (NTU) : 5 to 15, up to 0.5 m,
Turbidity (NTU) : ＞15, up to 0.2 m; Main Stream: 50 Hz: 20 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720); Sub-Stream: 50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480); Third Stream: 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480); Video Compression: Main stream: H.265/H.264 /H.265+/H.264+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264; Video Bit Rate: 32 Kbps to 8 Mbps; H.264 Type: Baseline Profile,Main Profile,High Profile; H.265 Type: Main Profile; Bit Rate Control: CBR,VBR; Scalable Video Coding (SVC): H.265 and H.264 encoding; Region of Interest (ROI): 5 fixed regions for main stream and sub-stream; Target Cropping: Yes; Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, SSL/TLS, WebSocket, WebSockets; Simultaneous Live View: Up to 20 channels; API: Open Network Video Interface, ISAPI, SDK, ISUP; User/Host: Up to 32 users
3 user levels: administrator, operator, and user; Network Storage: NAS (NFS, SMB/CIFS),CVR,NVR,Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.; Client: iVMS-4200, Hik-Connect, Hik-Central; Web Browser: Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+; Image Parameters Switch: Yes; Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser; Day/Night Switch: Day,Night,Auto,Schedule,Alarm Trigger; Wide Dynamic Range (WDR): 120 dB; Image Enhancement: BLC,HLC,3D DNR,Defog; Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.; SNR: ≥ 50 dB; Privacy Mask: 8 programmable polygon privacy masks; Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port; On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 128 GB,
*You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing.; Basic Event: Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error); Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection,object removal detection,scene change detection; Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture; Power: 36 VDC ± 20%, 0.5 A, max. 18 W, two-core terminal block
PoE: IEEE 802.3at, Class 4; Material: 316L and anti-corrosion coating; Dimension: 210.6 mm × 208 mm × 224 mm (8.29″ × 8.19″ × 8.82″); Package Dimension: 700 mm × 530 mm × 365 mm (27.6″ × 20.9″ × 14.4″); : Approx. 8.340 kg (18.387 lb.); With Package Weight: Approx. 10.985 kg (24.218 lb); Startup and Operating Conditions: -10 °C to 60 °C (14 °F to 140 °F). Humidity 100% or less (non-condensing); Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian; General Function: Anti-banding, heartbeat, mirror, flash log, password reset via email, pixel counter; Cable Length: 15 m (49.2 ft.) (included); EMC: CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015; Safety: UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1; Protection: IP68 (IEC 60529-2013) (within 15 m underwater)
