Hikvision 55-inch Slim Floor Standing Digital Signage DS-D6055UN-D/S

Hikvision DS-D6055UN-D/S 55-inch ultra-narrow bezel splicing screen. Full HD resolution for seamless video wall display.

SKU: DS-D6055UN-D/S Category: Brand:
Guaranteed Safe Checkout

The Hikvision DS-D6055UN-D/S is a 55-inch ultra-narrow bezel splicing screen. It is designed for seamless video wall display, with a super-narrow bezel that minimizes the gap between screens. The screen features a full HD resolution and a wide viewing angle, making it an ideal solution for a variety of applications, including retail, transportation, and corporate environments.

Specifications

Product Model: DS-D6055UN-D/S; Screen Size: 55 inch; Resolution: 2160 × 3840; Active Display Area: 1209.6 (H) × 680.4 (V) mm; Pixel Pitch: 0.315 (H) mm × 0.315 (V) mm; Backlight: E-LED; Viewing Angle: 178°(H)/178°(V); Brightness: 500 cd/m²; Contrast Ratio: 1200:1; Color Depth: 10 bit (8 bit + FRC); Response Time: 8 ms; Color Gamut: 72% NTSC; Reliability: 7 × 24h; Refresh Rate: 60 Hz; Haze: 25%; Display Ratio: 9 : 16; Panel Type: IPS; Operation System: Android 13; Processor: Cortex-A55, 4-core, main frequency 1.92 GHz; Memory: 4 GB; Built-in Storage: 32 GB EMMC; Video & Audio Input: HDMI 2.0 (HDCP 2.2) × 1; Video & Audio Output: Speaker (8Ω 5 W) × 2; Network Interface: RJ45 × 1, Wi-Fi (2.4G/5G, 802.11 a/b/g/n/ac/ax) × 1, RS232 in × 1, RS232 out × 1; Data Transmission Interface: USB 2.0 × 1, USB 3.0 × 1, BT 5.4 × 1; Input Voltage: 100 to 240 VAC, 50/60 Hz; Standby Consumption: ≤ 0.5 W; Power Consumption: 108 W (typ), 155 W (max); Working Temperature: 0 ℃ to 40 ℃ (32 ℉ to 104 ℉); Working Humidity: 10% to 80% RH (Condensation); Storage Temperature: -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉); Storage Humidity: 10% to 90% RH (Condensation); Mounting Type: Floor standing; Product Dimensions (W × H × D): 740 (W) mm × 1886 (H) mm × 480 (D) mm(With Stand)
727 (W) mm × 1776 (H) mm × 63.8 (D) mm(Without Stand); Package Dimensions (W × H × D): 840 (W) mm × 1895 (H) mm × 155 (D) mm; Net Weight: 46.5 kg; Gross Weight: 52 kg; Packing List: Digital signage × 1, stand × 1, power cord × 1, remote control × 1, user manual × 1, quick start guide × 1, Regulation Compliance and Safety Information × 1, stand fixed with M8 screw × 6, key × 2, foot pad × 4, energy efficiency label × 1, caster wheel × 4, wheel fixed with M4 screw × 16, Base fixed bracket × 2,Base fixed bracket with M4 screw × 4, Expansion screw × 2

DataSheet

Click Here for the DataSheet
