Hikvision 6 Ports LED Controller DS-DT60C-01HI06NO

Specifications

Brightness Control: 1 to 100 tunable (level-by-level white balance); Input Frame Rate: 25 Hz to 60 Hz; Grey Level: 256; Display Color: 16 MP; Processing Depth: 8 bit; Image Scaling: Supported; Product Model: DS-DT60C-01HI06NO; Chassis Height: 1 U; Chassis Width: Half-width; Product Type: LED controller; Light Sensor Port: Not supported; Average Consumption: 14 W; Power Interface Quantity: 1; Power Interface: 100 to 240 VAC, 50/60 Hz; USB Interface: 1 channel of USB 2.0; Control Network Port: 2 × 10/100/1000 Mbps self-adaptive Ethernet port (RJ-45)
Connects to the external network and supports multi-device network cascade management.; Background Images: 2; Background Resolution: Min.: 640 × 480, Max.: 1920 × 1200; Background Format: JGP/JPEG; Working Temperature: -10°C to 50°C; Storage Humidity: 10% to 90%; Working Humidity: 10% to 90%; Storage Temperature: -10°C to 50°C; Packaging Size (W × H × D): 353 mm × 237 mm × 89 mm (13.90 inch × 9.33 inch × 3.50inch); Net Weight: 1.18 kg (2.60 lb); Gross Weight: 1.62 kg (3.57 lb); Dimensions (W × H × D): 210 mm × 180 mm × 42 mm (8.27 inch × 7.09 inch × 1.65 inch); Packing List: 1 × AC power cord, 1 × connecting bracket, 1 × mounting bracket, 1 × RS-485 green Phoenix contact for central control device, 1 × regulatory compliance and safety information manual, 1 × RF remote control; Audio Input Interfaces: 1; Audio Input Interface Type: 1 channel of embedded HDMI input; Audio Output Interfaces: 1; Audio Output Interface Type: 3.5 mm audio output; Video Input Interfaces: 1; Video Input Interface Type: HDMI 1.4; Max. Video Input Resolution: 1080P; Video Input Resolution: HDMI 1.4 port:
Max. resolution: 1920 × 1200@60 Hz
Min. resolution: 320 × 180@60 Hz
Supports custom resolution. Total resolution should be no more than 2.6 MP@60 Hz
Max. width: 144 to 4096, alignment: 2 alignment
Max. height: 144 to 4096, alignment: 1 alignment
Supports HDCP 1.4. Interlacing signal input is not supported.; Video Input Processing Feature: Processing depth: 8 bit
Sampling format:
RGB: 444
YUV: 444
YUV: 422; Max. Video Output Resolution: 3900000; Loading Capacity for Video Output to LED: Single port load 650000,
Width 144 – 5120,
Height 64 – 5120,
Width must be a multiple of 2 and height must be a multiple of 1; LED Loading Interfaces: 6; LED Loading Interface Type: RJ-45; Loading Mode: Mini loading: single port load 650000
Standard loading: single port load 2925000 (only available on network ports 1 and 2); Remote Control: Supports IR remote control; Button: +: increase brightness
-: decrease brightness
Source: change signal source; Serial Interface: 1 × debugging serial port (4-pin connector) + 1 × RS-485 central control serial port (green Phoenix contact)
Baud rate: 115200, data bit: 8; Indicator: Active: The device is running.
Source: The signal source is accessed.
Error: The device operation exception occurs.; Power Switch: On: The device is started and running.
Off: The device is not powered on or is not started.; IR Input: 1 × 3.5 mm connector
Supports the access of IR remote control.
