Hikvision 86-inch 4K Interactive Display DS-D5C86RB/B2L

Specifications

Product Model: DS-D5C86RB/B2L; Screen Size: 86 inch; Backlight: DLED; Pixel Pitch: 0.164 (H) × 0.493 (V) mm; Resolution: 3840 × 2160 @60 Hz; Brightness: 480 cd/m² (Typ.); Color Depth: 10 bit; Display Color: 1.07 G; Response Time: 5 ms; Panel Type: VA; Contrast Ratio: 5000:1 (Static)
30,000:1 (Dynamic); Color Gamut: 72% NTSC (CIE1931) (Typ.); Refresh Rate: 60 Hz; Viewing Angle: 178° (H)/178° (V); Aspect Ratio: 16:9; Surface Hardness: 9H (Pencil)
7 (Mohs); Surface Glass: Anti-Glare & Anti-Fingerprint glass; Surface Haze: 25% Haze; Glass Bonding Method: Zero Lamination; Display Area: 1895.04 × 1065.96 mm; Working Duration: 7 × 16 H; Transmittance: 88% ± 3; Lifespan: 50,000 hours; Type: Infrared Touch Screen; Touch Point: Up to 50-point multi-touch; Touch Response Time: ≤ 2 ms; Minimum Touch Object: ≥ 1.5 mm (≥ 90% touching area); Touch Precision: ± 0.5 mm (≥ 90% touching area); Touch Resolution: 32768 × 32768; Operation System: Android 14.0; Memory: 8 GB; Built-in Storage: 128 GB; Processor: Quad-core Cortex-A76 × 4（2.4 GHz）and quad-core Cortex-A55 × 4（1.8 GHz）; GPU: Mali-G610 MC4; HDCP Version: 2.3 & 2.0 & 1.4; Pixel: Pixel 48 MP for Photos & 8 MP for Video; Camera Function: Support intelligent switching between Android system, OPS, and PC.; Field Angle: 93.4° (diagonal), 84.5° (horizontal), 54.1° (vertical); Distortion: ≤ 2.5%; Camera Resolution Ratio: Up to 4K; Specification: Omni-directional 8-array layout; Mic Function: Echo reduction and smart noise-cancellation; Voice Distance: 12 m; Sampling Rate: 32 K; Mic Depth: 16 bit; Loudspeaker: Built-in 2 × 20 W + 25 W loudspeaker;; Bluetooth: Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.4; NFC: Support card reader
13.56 MHz, (ISO 14443A/ ISO 14443B/ ISO 15693); Light Sensor: Yes; Image Processing Technology: Support 3D digital noise reduction, face detection, automatic white balance, automatic purple edge removal, automatic defogging; support shadow correction.; Audio Processing Technology: Support dereverberation, adaptive noise reduction, adaptive non-stationary noise reduction, adaptive echo cancellation, automatic gain control, automatic electrical level control, sound source localization, speech dynamic detection, digital beam forming, speech detection.; Humidity and Temperature Sensor: Relative humidity accuracy: up to ± 1.5 %RH; Temperature accuracy: up to ± 0.1 °C; Video & Audio Input: HDMI 2.0 × 3（Front x 1; Rear x 2; Support HDCP2.3 & 2.0 & 1.4; Support HDMI CEC protocol）
VGA × 1（Rear）
Audio × 1（Rear）; Video & audio output: HDMI 2.0 × 1（Rear）
Audio × 1（Rear）
SPDIF × 1（Rear）; Control interface: TOUCH-USB 3.0 × 1（Front × 1）
TOUCH-USB 2.0 × 2（Rear × 2）
RS232 × 1（Rear）; Network Interface: LAN (1000 Mbps) × 2（Rear）
Wi-Fi AP & Station, 2.4 G/5 G
Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP; Data Transmission Interface: USB 3.0 × 4（Front × 2; Rear × 2）
USB 2.0 × 1（Rear）
Type-C × 2 (Front × 1; Rear × 1; Support USB 2.0, 100 W charging functions, DP IN 1.2 ); Power Supply: 100 to 240 VAC, 50/60 Hz; Standby Consumption: ≤ 0.5 W; Average Consumption: < 274 W; Working Temperature: 0 °C to 40 °C (32 °F to 104 °F); Working Humidity: 10%~90% RH; VESA: 800 mm × 600 mm (4 × M8-25 mm); Accessory: Wall mount bracket, hook, user manual, touch writing pen, packing list, 3 M touch USB cable, 3.5 M HDMI cable (2.0), 3 M power cable, remote control, screen cleaning cloth.; Package Dimensions (W × H × D): 2157 × 1345 × 223 mm; Net Weight: 58.9 ± 0.5 kg; Gross Weight: 78.9 ± 0.5 kg; Product Dimensions （With Wall Attachment）: 1960.4 × 1173.7 × 114.5 mm; Product Dimensions （Without Wall Attachment）: 1960.4 × 1173.7 × 82.5 mm
