The Hikvision DS-QAZ0510G1 is a professional audio zone controller for public address (PA) systems. It allows for the management and control of audio output in specific zones, ensuring targeted and efficient broadcasting. The device is built for seamless integration with Hikvision PA system components, offering flexible configuration and reliable performance.
Hikvision Analog Pendant Speaker 10W (DS-QAZ0510G1)
Hikvision DS-QAZ0510G1 audio zone controller. Manages and controls audio output in specific zones for efficient PA systems.
Specifications
Impedance: 8Ω; Rated Power: 10W; Total Harmonic Distortion (THD): ≤1%; Sensitivity(1 m, 1 W): 89dB; Max. Acoustic Pressure: 98dB; Frequency Response: 120Hz~20kHz(-10dB); Speaker Unit: 1 × 1.0-inch tweeter and 1 × 6.5-inch woofer; Coverage Angle: Conical Coverage: 88°; Audio In: Constant voltage input: 100 V/Constant voltage input: 70 V/Constant impedance input: 8 Ω; Voltage Input: 100V: 10W、5W、2.5W
70V:10W、5W、2.5W、1.25W
8Ω; Material: Main body: PC
Base: ABS; Dimension: Ø242.78 mm × 214.78 mm (9.56″ × 8.46″); : Approx. 2.7 kg (5.95 lb.); Language: 5 languages: English, French, Spanish, German, Italian; Package Dimension: 305 mm × 305 mm × 315 mm (12.01″ × 12.01″ × 12.4″); With Package Weight: Approx. 2.9 kg (6.49 lb.); Packing List: Device × 1
Regulatory Compliance and Safety Information × 1; Operating Temperature: -10 °C to 45 °C; Operating Humidity: <90% (No condensation)
