Hikvision Dual-Sensor Parking Camera with audio function DS-TCP440-DB(ES)(2.8mm)

Specifications

Lens Type: 2.8mm; Aperture: 2.8mm：F2.0; Focal Length & FoV: 2.8 mm, horizontal FoV: 103.7±5°, vertical FoV: 56.1±5°, diagonal FoV: 121.8±5°; Focus: Fixed; Image Format: JPEG; Capture Resolution: 2560 x 1440 (default)2688 × 1520, 1920 × 1080, 1280 × 720; Smart Recognition: vehicle entering/exiting parking space status, parking spacestatus detection,Intelligent Detection; Capture Picture Overlay: Lane No., Capture Time, Anti-counterfeiting Code, Capture No., Vehicle Entry/Exit Direction, etc; WDR: 140db; Defog: supported; Main Stream: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720); Sub-Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480); Image Settings: Saturation, brightness, contrast, white balance, and gain are adjustable by client,software or web browser.; Day/Night Switch: Auto/Scheduled/Manual; WDR Switch: On, Time, Brightness; Frame Rate: 25fps; ROI: 8 regions respectively for main stream and sub-stream, 6 levels for each region.; Video Compression: H.265/H264/MJPEG; H.264 Type: Low profile
Medium profile
High Profile; Video Bit Rate: 32 Kbps to 16 Mbps; Bit Rate Type: Constant, Variable; Scalable Video Coding (SVC): MJPEG , H.265 and H.264 encoding; Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported; Protocol: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNSDDNS,RT,RTSP,RTCP,NTP,SNMP，OTAP; API: ONVIF(PROFILE S,PROFILE G), ISAPI, SDK; Client: HikCentral,SDKdemo,DS-TPM400; Web Browser: Plug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+; Security: One-key restoration, password protection, watermark; Indicator Interface: 3*LED lamp interface; Network Interface: 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interface; Min. Illumination: Color: 0.019 Lux @ (F1.9, AGC OFF)
B/W: 0.011 Lux @ (F1.9, AGC OFF); Sensor Type: 1/3″ Progressive Scan CMOS; Max. Resolution: 2560 × 1440; Day/Night Switch: Supported; Shutter: 1 to 1/100,000 s; Number of Detected Parking Space: Max 6; ANPR Supported Country/Region: Middle East:
The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain
Africa:
Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria
Asia-Pacific:
Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, HongKongChina, Macao, TaiwanChina, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka
America:
Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala
Europe:
Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina
Speaking Regions:
Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan; Resolution: 4 MP; Working Temperature & Humidity: -20 °C to 50 °C (-4 °F to 122 °F); Consumption: Max. 6.5 W; : 0.525 kg (1.1 lb.); Working Temperature and Humidity: -20 °C to 70 °C (-4 °F to 158 °F)
5% to 95% @ 40°C (non-condensing); Working Environment: 90% or less (non-condensing); Power Supply: Hikvision PoE, or 12 to 24 VDC wide-range voltage; Dimensions: 170 × 121 × 105 mm (6.7 × 4.8 × 4.2 inch); Weight (with Package): 1 kg (2.2 lb.); Dimensions (with Package): 275 * 205 * 175 mm(10.8 * 8.1 * 6.9 inch); Storage Temperature and Humidity: Temperature: -20 °C to 70 °C (- 4°F to 158 °F)
Humidity: 95% (non-condensing); Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
