Hikvision Network Cabinet Speaker POE 10W (DS-QAZ1110G1R-BE)

Specifications

Type: electret; Amount: 2; Frequency Response: 100 Hz to 18 kHz; Sensitivity: -42 dBV/Pa; Sampling Rate: 48 kHz; Quantization Bits: 16 bit; Rated Power: 10 W; Impedance: 8 Ω; Max. Acoustic Pressure: 100 dBSPL; Sensitivity(1 m, 1 W): 90 dB; Direction: All directions; Frequency Response: 130 Hz to 17.5 kHz; SNR: 83 dB; Speaker Unit: 5.25′′ × 1; Coverage Angle: Horizontal: 135°
Vertical: 130°; Audio Algorithm: AEC、AGC、ANS、DRC; Audio Bit Rate: G.711ulaw(64 Kbps)/G.711alaw(64 Kbps)/MP3(128 Kbps)
Sampling bit width: 16 bits; Audio File Format: WAV、MP3、MP2、AAC; NTP Timing: Support; Broadcast: Regular broadcast, live broadcast, emergency broadcast; Two-Way Audio: Support; Speech Synthesis: Language Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French; Network Protocol: IPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP; Interface Protocol (API): ISAPI, ISUP, SIP, RTP,ONVIF; Client: Hik-Partner Pro, iVMS-4200, Hik-Connect, HikCentral Professional; Communication Method: Support wired network and bluetooth communication; Ethernet Interface: RJ45 10 M/100 M Adaptive Ethernet port × 1; Local Storage: Built-in 64 GB EMMC (Audio file storage is 55 GB.); API: ISAPI, ISUP, SIP,ONVIF; Audio In: 3.5 mm audio interface × 1; LED Indicator: Solid green: normal working
Flashing green: intercom in progress
Solid red: start or network disconnection
Flashing red: upgrading; Reset: Support; Volume Knob: Support; Power: PoE(IEEE 802.3at class 4); Material: Main body&Front cover：plastic, bracket: metal; Operating Temperature: -30 °C to 60 °C (-22 °F to 140 °F); Operating Humidity: ＜90% (No condensation); Dimension: 268.4 mm × 180.4 mm × 125.12 mm (10.57″ × 7.1″ × 4.93″); Package Dimension: 340 mm × 306 mm × 180 mm (13.39″ × 12.05″ × 7.09″); : Approx. 2 kg (4.4 lb.); Color: White or black appearance optional; With Package Weight: Approx. 2.2 kg (4.8 lb.); Packing List: Device × 1
U-shaped bracket × 1
Screw pack × 1
Installation sticker × 1
Regulatory Compliance and Safety Information × 1; Language: 41 languages: English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kirgiz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese; Bluetooth: Bluetooth 5.0, 10 m; RF: CE-RED: EN 301489-1 V2.2.3 (BT or 2.4G), EN 301489-17 V3.2.4 (BT or 2.4G), EN 300 328 V2.2.2 (BT or 2.4G), EN62311 2020(BT or 2.4G)
RCM: EN 300 328 V2.2.2 (BT or 2.4G), AS/NZS 2772.2:2016+A1:2018, ARPANSA RPS S-1 Radiation Protection Series S-1 (Rev.1), ARPANSA RPS S01 Advisory Note
IC ID: RSS-247(BT or 2.4G)
ANATEL: Resolution No. 680/2017,Act No. 14448/2017,Act No. 950/2018,Act No. 1120/2018; EMC: CE-EMC: EN 55032:2015+A11:2020+A1:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019+A2:2021, EN 55035:2017+A11:2020 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7; Safety: CB: IEC 62368-1:2014
CE-LVD: EN 62368-1:2014/A11:2017; Environment: CE-RoHS: 2011/65/EU
WEEE: 2012/19/EU
Reach: Regulation (EC) No 1907/2006
