Hikvision Network Column Speaker 120W (DS-QAZ14A2G1)

Specifications

Type: electret; Amount: 2; Frequency Response: 100 Hz to 20 kHz; Sensitivity: -42 dBV/Pa; Sampling Rate: 48 kHz; Quantization Bits: 16 bit; Rated Power: 120 W; Impedance: 4 Ω; Max. Acoustic Pressure: 107.5 dBSPL; Sensitivity(1 m, 1 W): 86 dB; Direction: All directions; Frequency Response: 100 Hz to 20 kHz; SNR: 85 dB; Speaker Unit: Low frequency 5.25′′ × 2，high frequency 1′′ × 1; Coverage Angle: Horizontal: 190°
Vertical: 140°; Audio Algorithm: AEC、AGC、ANS、DRC; Audio Bit Rate: G.711ulaw(64 Kbps)/G.711alaw(64 Kbps)/MP3(128 Kbps)
Sampling bit width: 16 bits; Audio File Format: MP3, WAV; NTP Timing: Support; Broadcast: Regular broadcast, live broadcast, emergency broadcast; Two-Way Audio: Support; Speech Synthesis: Language Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French; Network Protocol: IPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH; Interface Protocol (API): ISAPI, ISUP, SIP, RTP,ONVIF; Client: Hik-Connect, ivms/4200, HikCentral Professional, Hik-Partner Pro, NVR, MileStone; Communication Method: Support wired network communication; Ethernet Interface: RJ45 10 M/100 M Adaptive Ethernet port × 1; Local Storage: Built-in 4 GB EMMC (Audio file storage is 1 GB.); API: ISAPI, ISUP, SIP,ONVIF; Alarm: Alarm input × 2; Audio In: Line in × 1, phoenix terminal; LED Indicator: Green light on: normal
Green light flash: intercom in progress
Red light on: start or network disconnection
Red light flash: upgrading; Reset: Support; Power: 100 VAC to 240 VAC; Material: Metal; Operating Temperature: -40°C to 60 °C(-40 °F to 140 °F); Operating Humidity: ＜90% (No condensation); Dimension: 160 mm × 160 mm × 446.8 mm(6.3″ × 6.3″ × 17.59″); Package Dimension: 715 mm × 265 mm × 250 mm(28.1″ × 10.4″ × 9.8″); : Approx. 6.2 kg(13.67 lb.); Color: White; With Package Weight: Approx. 8 kg(17.64 lb.); Packing List: Device × 1
Screw pack × 1
Support × 1
L-shaped wrench × 1
Regulatory Compliance and Safety Information × 1; Language: 41 languages: English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kirgiz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese; Protection: IP66: IEC 60529-2013; EMC: CE-EMC: EN 55032:2015+A11:2020+A1:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019+A2:2021, EN 55035:2017+A11:2020 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7; Safety: CB: IEC 62368-1:2014
CE-LVD: EN 62368-1:2014/A11:2017; Environment: CE-RoHS: 2011/65/EU
WEEE: 2012/19/EU
Reach: Regulation (EC) No 1907/2006
