Hikvision Network Frameless Ceiling Speaker PoE 10W (DS-QAZ1610G1-BE)

Specifications

Network Protocol: IPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP; Type: MEMS; Amount: 2; Frequency Response: 100 Hz to 10 kHz; Sensitivity: -38dBV/Pa; Impedance: 8Ω; Rated Power: 10W; Total Harmonic Distortion (THD): ≤1%; Sensitivity(1 m, 1 W): 89dB; Max. Acoustic Pressure: 98dB; Frequency Response: 120Hz~20kHz(-10dB); Speaker Unit: 1 × 1.0-inch tweeter and 1 × 6.5-inch woofer; Coverage Angle: Conical Coverage: 88°; Audio Algorithm: AEC、AGC、ANS、DRC; Audio Bit Rate: G.711ulaw（64 Kbps）/G.711alaw（64 Kbps）/MP3（128 Kbps）
Sampling bit width: 16 bits; Speech Synthesis: Language Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French; Number of Secondary Speaker: Hi-PoE/PoE++ (802.3bt) 60W: support 3* 10W sub speakers
Hi-PoE/PoE++ (802.3bt) 90W: support 3* 10W sub speakers
PoE midspan injector 60W: support 3* 10W sub speakers
PoE midspan injector 75W: support 3* 10W sub speakers
24 V, 5 A, max. 60 W: support 3* 10W sub speakers; Secondary Speaker Connection Method: Voltage Input; Alarm: Alarm in; Network Interface: RJ45 10 M/100 M Adaptive Ethernet port × 1; Local Storage: Built-in 64 GB EMMC (Audio file storage is 55 GB.); Audio In: 3.5 mm audio interface × 1; LED Indicator: Solid green: normal working
Flashing green: intercom in progress
Solid red: start or network disconnection
Flashing red: upgrading; Reset: Support; Power: 24 VDC ± 10%, 2.5 A, max. 60 W, PoE: 50 V to 57 V, 0 A to 1.6 A, max. 71 W; Material: Main body: PC
Base: ABS; Dimension: Ø242.78 mm × 192.7 mm (9.56″ × 7.59″); : Approx. 2.7 kg (5.95 lb.); Language: 41 languages: English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kirgiz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese; Package Dimension: 305 mm × 305 mm × 315 mm (12.01″ × 12.01″ × 12.4″); With Package Weight: Approx. 2.9 kg (6.49 lb.); Packing List: Device × 1
Regulatory Compliance and Safety Information × 1
2-pin phoenix connector × 1
4-pin phoenix connector ×1; Bluetooth: Bluetooth 5.0, 10 m; Operating Temperature: -10 °C to 45 °C; Operating Humidity: ＜90% (No condensation)
