Hikvision On-street Parking Terminal DS-TPE400

Specifications

Number of HDD: 1 × 3.5″ SATA hard disk and 1 × 2 TB hard disk. Up to 8 TB hard disk is supported.; Parking Data Storage and Uploading: Supports roadside parking vehicles information (videos and pictures) storage.
Supports uploading data via EHome, SDK, and HTTP.; Video Recording: Supports video storage. The set stream and hard disk capacity determine the video retention duration.; Data Uploading: Supports ANR (Automatic Network Replenishment) and manual re-upload of traffic data.; Operating System: Embedded Linux operation system; Local Operation: Web; Indicator: Power indicator, alarm indicator, hard disk indicator, working indicator; Alarm Input: 1; Alarm Output: 1; RS-232: 2; RS-485: 1; USB: 1 × USB 2.0 interface; Network Interface: 4 × 100M Ethernet interfaces, 2 × 10M/100M/1000M self-adaptive Ethernet interfaces, and 2 × gigabit SFP optical fiber interfaces
8 × 100M and 1 gigabit optical port compose the internal network, and the other 1 gigabit combo port is for the external network. The network segment of the internal network can be different from that of the external network. Supports accessing camera across network segments, which saves the system IP address resources.; Working Temperature & Humidity: -30 °C to 70 °C (-22 °F to 158 °F)
10% to 90%; Power Supply: 12 VDC/5 A adapter; Working Consumption: 20 W; Dimensions: 245 mm × 175 mm × 60 mm (9.65″ × 6.89″ × 2.36″); : 2.0 kg (4.4 lb.) (with 1 hard disk); Weight (with Package): 2.5 kg (5.5 lb.); Dimensions (with Package): 450 × 240 × 105 mm (17.7 × 9.45 × 4.13 inch)
