Hikvision P1.2 SMD 600nits DS-D4012CW-2F/A

Specifications

Product Model: DS-D4012CW-2F; Product Type: Small Pixel Pitch Indoor Full-color LED Display; Pixel Configuration: SMD Triad LED; Pixel Pitch: 1.25 mm; Pixel Pitch Category: P1.2; Pixel Density: 640000 dots/㎡; Modules Component: 2 × 2; Dimensions (W × H × D): 600 mm × 337.5 mm × 29.5 mm (23.622″ × 13.287″ × 1.161″); Resolution: 480 × 270; Area: 0.2025 ㎡; : 3.4 kg; Cabinet Material: Aluminium die casting; Maintenance Method: Front maintenance for all components; Dimensions: 300 × 168.75 mm; Module Resolution: 240 × 135; White Balance Brightness: 600 cd/㎡; Color Temperature: 3000-10000 K adjustable; Viewing Angle: 160°(H)/160°(V); Contrast Ratio: 5000:1; Color Uniformity: ≤ ± 0.003Cx，Cy; Brightness Uniformity: ≥ 97％; Driving Method: Constant current driving; Frame Frequency: 60 Hz; Refresh Rate: 3840 Hz; Grey Level: 16 bit; Max. Consumption: ≤ 460 W/㎡ （600nits）; Average Consumption: ≤ 160 W/㎡; Input Voltage: 100~240 VAC ± 10％; Working Temperature: -10 ℃ to 40 ℃ (14 ℉ to 104 ℉); Working Humidity: 10% to 60% RH (without condensation); Storage Temperature: -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉); Storage Humidity: 10% to 85% RH (without condensation); Package Dimensions (W × H × D): Module: 4-in-1(443X360X52mm) Structure: 5-in-1(708X393X433mm); Packing List: Regulatory Compliance and Safety Information × 1
Connecting screws, light beads, driver IC, iron sheets; G.W.: 4.5 kg（1 package in 1 box）; Net Weight: 3.4 kg; Modular Bracket: DS-DL116033W 1*1;DS-DL126033W 1*2;DS-DL226033W 2*2
