Hikvision P8 Outdoor LED Display Unit

Specifications

Pixel Configuration: SMD Triad LED; Pixel Pitch Category: P8.0; Pixel Pitch: 8 mm; Modules Component: 3 × 2; Dimensions (W × H × D): 960 mm × 960 mm × 100 mm; Resolution: 120 × 120; Area: 0.9216 m²; : 28 Kg; Pixel Density: 15625 dots/m²; Lamp Board Housing: With housing; Cabinet Material: Aluminum Profile; Maintenance Method: Front/Rear maintenance; Protection Level: IP66; Lamp Encapsulation: 2727(Copper); Control System: Hikvision; White Balance Brightness: 6500 nit (Factory preset brightness)
7000 nit (Peak); Color Temperature: 9300K adjustable; Viewing Angle: Horizontal 160°, vertical 130°; Contrast Ratio: ≥ 8000:1; Color Uniformity: ≤ ± 0.003Cx，Cy; Brightness Uniformity: ≥ 97％; Driving Method: Constant current driving; Frame Frequency: 50/60 Hz; Refresh Rate: Up to 3840 Hz; Grey Level: 14~16 bit adjustable; Power Supply: 110~220 VAC ± 15%; Max. Consumption: ≤475 W/m² （6500nits）; Average Consumption: ≤160 W/m² (6500nits); Working Temperature: -40 ℃ to 60 ℃ (-40 ℉ to 140 ℉); Working Humidity: 10%~95%RH (No condensation); Storage Humidity: 10%~95%RH (No condensation); Storage Temperature: -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉); Gross Weight: 30.15kg /1 in 1; Package Dimension (W × H × D): 1140 (W) mm × 244 (H) mm × 1068 (D) mm; Lifespan: Lamp 100,000 hours
