Hikvision Polymer 4MP Underwater Fixed Bullet

Specifications

Image Sensor: 1/3.0″ Progressive Scan CMOS; Max. Resolution: 2560 × 1440; Min. Illumination: Color: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with light; Shutter Time: 1/3 s to 1/100,000 s; Lens Type: Fixed focal lens, 2.8, and 4 mm optional; Focal Length & FOV: 2.8 mm, horizontal FOV 99.5°, vertical FOV 55.5°, diagonal FOV 116.1°
4 mm, horizontal FOV 76.8°, vertical FOV 41.5°, diagonal FOV 90.8°; Aperture: F2.0; Supplement Light Type: White Light; Supplement Light Range: NTU: 0 to 5, up to 1 m,
NTU: 5 to 15, up to 0.5 m,
NTU: >15, up to 0.2 m; Main Stream: 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720); Sub-Stream: 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360); Video Compression: Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG; Video Bit Rate: 32 Kbps to 8 Mbps; H.264 Type: Baseline Profile,Main Profile,High Profile; H.265 Type: Main Profile; Scalable Video Coding (SVC): H.264 and H.265 encoding; Region of Interest (ROI): 1 fixed region for main stream; Target Cropping: Yes; Protocols: SSL/TLS, RTSP, TCP/IP, RTP, HTTP, QoS, PPPoE, ICMP, DDNS, UDP, UPnP, IGMP, DHCP, DNS, SNMP, IPv4, IPv6, FTP, HTTPS, 802.1X, NTP; Simultaneous Live View: Up to 6 channels; API: ONVIF (Profile S, Profile G),ISAPI,SDK,ISUP; User/Host: Up to 32 users
3 user levels: administrator, operator, and user; Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), WSSE and digest authentication for ONVIF,basic and digest authentication for HTTP/HTTPSF, RTP/RTSP over HTTPS, security audit log, control timeout settings; Client: iVMS-4200, Hik-Connect, Hik-Central; Web Browser: Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+; Image Settings: Rotate mode,saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser; Day/Night Switch: Day,Night,Auto,Schedule; Wide Dynamic Range (WDR): 120 dB; Image Enhancement: BLC,HLC,3D DNR; Privacy Mask: Yes; Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.; Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port; On-Board Storage: Built-in eMMC storage, 64 GB; Reset Key: Yes; Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error); Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection,scene change detection,defocus detection; Linkage: Upload to FTP, notify surveillance center, send email, trigger recording, trigger capture; Power: 12 VDC, 0.88 A, max. 10.6 W, two-core terminal terminal block,
PoE: IEEE 802.3af, Class 3, max. 12.95 W; Material: -LY/LD/LRY/LRD: PTS+50%GF + stainless steel
-L/LR: PTS+50%GF; Dimension: -L: 114 mm × 100.9 mm × 114.9 mm (4.49″ × 3.97″ × 4.52″),
-LR: 122.1 mm × 122.7 mm × 206.6 mm (4.81″ × 4.83″ × 8.13″),
-LD/LY: 192 mm × 169.1 mm × 172 mm (7.56″ × 6.66″ × 6.77″),
-LRD/LRY: 196 mm × 185.4 mm × 264 mm (7.72″ × 7.30″ × 10.39″); Package Dimension: 498 mm × 342 mm × 182 mm (19.60” × 13.46” × 7.17”); : -L: approx. 1825 g (4.02 lb.)
-LR: approx. 2040 g (4.50 lb.)
-LRD: approx. 2845 g (6.27 lb.)
-LRY: approx. 2490 g (5.49 lb.)
-LY: approx. 1760 g (3.88 lb.)
-LD: approx. 1765 g (3.89 lb.); With Package Weight: -L: approx. 2825 g (6.23 lb.)
-LR: approx. 3540 g (7.80 lb.)
-LRD: approx. 4020 g (8.86 lb.)
-LRY: approx. 4038 g (8.90 lb.)
-LY: approx. 3345 g (7.37 lb.)
-LD: approx. 3300 g (7.28 lb.); Storage Conditions: -10 °C to 50 °C (14 °F to 122 °F); Startup and Operating Conditions: -10 °C to 50 °C (14 °F to 122 °F); Language: 9 languages: English, Italian, French, Portuguese, Spanish, Russian, Japanese, Korean, Thai; General Function: Heartbeat, mirror, flash log, password reset via e-mail, pixel counter, anti-banding; Wiper: -R: Yes; Cable Length: 10 m (32.81 ft.) (included); EMC: CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015; Safety: CB: IEC 62368-1: 2014,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1; Environment: CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006; Protection: IP68: IEC 60529-2013; Anti-Corrosion Protection: NEMA 4X (NEMA 250-2018),C5; Measurement Range: -LD/-LY/-LRD/-LRY:
Dissolved oxygen: 0 to 20 mg/L, 0 to 200% saturation,
Temperature: 0 °C to 50 °C (32 °F to 122 °F); Accuracy: -LD/-LY/-LRD/-LRY:
Dissolved oxygen: ±0.3 mg/L or ±3%,
Temperature: ±0.4 °C (±32.72 °F); Resolution: -LD/-LY/-LRD/-LRY: 0.01 mg/L
