Hikvision Pro Swing Barriers DS-K3B530X-L/MPg-Dp65

Specifications

Motor: Servo motor; MCBF: ≥ 12 million times; Communication protocol: ISAPI; Wired network: 10/100 Mbps self-adaptive Ethernet; Wi-Fi: For AP mode only; Network interface: 1; Lock control: 2; Exit button: 2; Alarm output: 2; RS-485: 4; RS-232: 4; Wiegand: NA; Fire alarm input: 1; Case input: 2; Access controller: Supplied; Supercapacitor: Supplied; Network switch: Not supplied; Power supply for face recognition module: Supported; Keyfob: Supported, order separtely; Card receiver: Optional; Card capacity: 700,000; Event capacity: 700,000; Card type: EM/M1/DESfire/Felica; Configuration via Web browser: Supported; Configuration via mobile Web browser: Supported; Audio prompt: Supported; AP mode: Supported; Throughput: 30 to 60 persons per minute
The actual throughput is affected by the person passing rate and passing method.; IR light detectors: 14 pairs; Lane width: For arcylic or stainless pipe:
550 mm to 1100 mm (21.65″ to 43.31″)
For full-height door wings:
Height1.2 m,1.4 m,1.6 m,1.8 m (max 900mm); Distance between barrier and ground: 1.2 m,1.4 m,1.6 m,1.8 m; Barrier material: Acrylic, Stainless steel pipe, Tempered glass; Pedestal material: SUS304 stainless steel 1.5mm(0.06”); Indicator: Yes; Power: 100 to 240 VAC; 50 to 60 Hz; Power consumption: 55W per lane; Working temperature: -20 °C to 65 °C (-4 °F to 149 °F); Working humidity: 0% to 95% (No Condensing); Protective level: IPX4; Dimensions: With packaging: 1610 mm (63.39”) × 410 mm (16.14”) × 1255 mm (49.41”);
Without packaging: 1500 mm (59.06”) × 130 mm (5.12”) × 1000 mm (39.37”);; : (Net) Left: 62.78 kg (138.4 lbs); Middle: 82.4 kg (181.7 lbs); Right: 64.78 kg (142.8 lbs);
(Rough) Left: 101.18 kg (223.1 lbs); Middle: 45.54 kg (286.4 lbs); Right: 103.18 kg (227.5 lbs);; Approval: CE/CE-LVD/CB/RoHS/REACH/WEEE; Lane width: 650;750;900;1100; Pedestal length: 1500 mm; Module selection: YES; Pedestal width: 130 mm; Wall distance: 20 mm; Base: YES; Barrier material: Acrylic glass; Application environment: Indoor and outdoor; Authentication mode: Face;QR code;Card; Card type: EM;M1;Desfire; Recommended width: 650 mm; Base model: DS-B530-BASE; Product type: Swing barrier; Remote controller type: 433Mhz;868Mhz; Movement Protrusion Width: 72 mm; Convert Face: NO; Door Height: Default(0.85m);1.6m; Door wing gap: Default:50mm
