Specifications
Image Sensor: [Bullet channel] 1/2.8″ Progressive Scan CMOS, [PTZ channel] 1/2.8″ Progressive Scan CMOS; Max. Resolution: [Bullet channel] 1920 × 1080, [PTZ channel] 1920 × 1080; Min. Illumination: [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;
[PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR; Shutter Speed: 1 s to 1/30,000 s; Day & Night: ICR; Zoom: [PTZ channel] 15 × optical, 16 × digital; Slow Shutter: yes; Focal Length: [Bullet channel]: 2.8 mm; [PTZ channel]: 5 to 75 mm, 15 × optical; FOV: [Bullet channel]:Horizontal field of view: 106.1°, Vertical field of view: 56.8°，Diagonal field of view: 126.5°;
[PTZ channel]:
Horizontal field of view: 54.8° to 4° (wide-tele),
Vertical field of view: 31.4° to 2.3° (wide-tele),
Diagonal field of view: 62.2° to 4.6°(wide-tele); Focus: auto,manual,semi-auto; Aperture: [Bullet channel]: F1.0; [PTZ channel]: F1.6; Zoom Speed: [PTZ channel]: approx. 2.3 s; Supplement Light Type: [PTZ channel]: IR; [Bullet channel]: White Light; Supplement Light Range: [PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m; Smart Supplement Light: Yes; Movement Range (Pan): 360°; Movement Range (Tilt): -15° to 90° (auto flip); Pan Speed: Pan speed: configurable from 0.1° to 80°/s, preset speed: 80°/s; Tilt Speed: Tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s; Proportional Pan: yes; Presets: 300; Preset Freezing: yes; Patrol Scan: 8 patrols, up to 32 presets for each patrol; Pattern Scan: 4 pattern scans; Park Action: preset,frame scan,tilt scan,patrol scan,random scan,auto scan,pattern scan,panorama scan; 3D Positioning: yes; PTZ Status Display: yes; Scheduled Task: Preset,pattern scan,patrol scan,tilt scan,auto scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output; Power-off Memory: yes; Main Stream: [Bullet channel]:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
[PTZ channel]:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720); Sub-Stream: [Bullet channel]:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
[PTZ channel]:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240); Third Stream: [Bullet channel]:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
[PTZ channel]:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240); Video Compression: H.265,H.264,MJPEG; Video Bit Rate: 32 kbps to 16384 kbps; H.264 Type: main profile,baseline profile,high profile; H.265 Type: main profile; Scalable Video Coding (SVC): yes; Region of Interest (ROI): 8 fixed regions for each stream; Audio Compression: G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC; Audio Bit Rate: 32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC); Audio Sampling Rate: 8 kHz,16 kHz,32 kHz,48 kHz; Environment Noise Filtering: yes; Protocols: DHCP,FTP,HTTPS,TCP/IP,ICMP,HTTP,SFTP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour,WebSocket,WebSockets; Simultaneous Live View: 20; API: Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP; User/Host: 32; Security: 802.1X authenticated access,MAC address binding,Authenticated username and password,IP address filter,HTTPS encryption; Network Storage: NAS (NFS, SMB/CIFS),auto network replenishment (ANR); Client: iVMS-4200,Hik-Connect; Web Browser: IE 10+, Chrome 57+, Firefox 52+, Safari 12+; Image Parameters Switch: Yes; Image Settings: sharpness,saturation,brightness,contrast; Day/Night Switch: day, night, auto, scheduled-switch; Wide Dynamic Range (WDR): 120 dB WDR; SNR: ＞52dB; Defog: Digital defog; Image Stabilization: EIS; Image Enhancement: BLC,HLC,3D DNR; Privacy Mask: [Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable; Regional Focus: yes; Regional Exposure: yes; Ethernet Interface: RJ45, self-adaptive 10M/100M Ethernet port; On-board Storage: Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB; Audio: 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω; Alarm: 1 alarm input, 1 alarm output; Reset: yes; Basic Event: Motion detection,video tampering alarm,exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot), alarm input and output; Smart Event: audio exception detection,region exiting detection,region entrance detection,intrusion detection,Line crossing detection; Linkage: [Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording, [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan); Face Capture: [Bullet channel] no,[PTZ channel] yes; Power: DC12V, PoE+; Dimension: Ø 166 mm × 375 mm (Ø 6.5″ × 14.7″); : Approx. 2.4 kg (13.2 lb.); Material: ADC12; Operating Condition: humidity lower than 90%RH ,-30℃ to 65℃ (-22°F to 149°F); General Function: mirror, password protection, watermark, IP address filter; Demist: Demist by heating the glass; Power Consumption and Current: Max. 24 W, including max. 2.6 W for heater and max. 11 W for supplement light; Protection: IP66 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection
