Specifications
Image Sensor: [Panoramic channel] 1/2.5″ Progressive Scan CMOS, [PTZ channel] 1/2.8″ Progressive Scan CMOS; Max. Resolution: [Panoramic channel] 3632 × 1632, [PTZ channel] 2560 × 1440; Min. Illumination: [PTZ channel] Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 lux with IR,[Panoramic channel] Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light; Shutter Speed: 1 s to 1/30,000 s; Day & Night: IR cut filter; Zoom: 25 × optical,16 × digital; Slow Shutter: yes; HLC: yes; 3D DNR: yes; Focal Length: [Panoramic channel] 2.8 mm, [PTZ channel] 4.8 to 120 mm; FOV: [Panoramic channel] horizontal field of view: 180°±10°, vertical field of view: 80°±5°, [PTZ channel] horizontal field of view: 55° to 3°; Focus: Auto,semi-auto,manual; Aperture: [Panoramic channel] F1.0, [PTZ channel] F1.6; Zoom Speed: [Panoramic channel] No, [PTZ channel] approx. 3.6 s; Supplement Light Range: IR distance: up to 200 m; White Light Distance: Panoramic channel: 30 m; Movement Range (Pan): 360°; Movement Range (Tilt): -15° to 90°; Pan Speed: Pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s; Tilt Speed: Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s; Proportional Pan: Yes; Presets: 300; Preset Freezing: Yes; Patrol Scan: 8 patrols, up to 32 presets for each patrol; Pattern Scan: 4 pattern scans, record time over 10 minutes for each scan; Park Action: Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan; 3D Positioning: Yes; PTZ Status Display: Yes; Scheduled Task: Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,aux output,dome adjust; Power-off Memory: Yes; Main Stream: [PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720),[Panoramic channel] 50 Hz: 25 fps (3632 × 1632, 3680 × 1656), 60 Hz: 30 fps (3632 × 1632, 3680 × 1656); Sub-Stream: [PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240),[Panoramic channel] 50 Hz: 25 fps (1200 × 536, 960 × 432), 60 Hz: 30 fps (1200 × 536, 960 × 432); Third Stream: [PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240),[Panoramic channel] No; Video Compression: Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264/MJPEG; Video Bit Rate: 32 Kbps to 16384 Mbps; H.264 Type: Baseline Profile,Main Profile,High Profile; H.265 Type: Main Profile; Scalable Video Coding (SVC): yes; Region of Interest (ROI): fixed region; Audio Compression: G.711,G.722.1,G.726,MP2L2,AAC-LC,PCM,MP3; Audio Bit Rate: 32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3); Audio Sampling Rate: 8 kHz,16 kHz,32 kHz,48 kHz; Environment Noise Filtering: yes; Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour,WebSocket,WebSockets,SRTP; Simultaneous Live View: 20; API: ISUP,SDK,ISAPI,Open Network Video Interface (Profile S, Profile G, Profile T); User/Host: 32; Security: Password protection,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),IP address filter; Network Storage: NAS (NFS, SMB/CIFS),auto network replenishment (ANR); Client: iVMS-4200,HikCentral Pro,Hik-Connect; Web Browser: IE 11+, Chrome 57+, Firefox 52+, Safari 12+, Edge79.0.309.65+; Image Parameters Switch: Yes; Image Settings: saturation, brightness, contrast, sharpness; Day/Night Switch: Day,night,auto,schedule; Wide Dynamic Range (WDR): [Panoramic channel] Digital WDR, [PTZ channel] 120 dB; SNR: ＞52dB; Defog: yes; Image Stabilization: yes; Image Enhancement: BLC,HLC,3D DNR; Privacy Mask: 24 programmable polygon privacy masks, mask color or mosaic configurable; Regional Focus: yes; Regional Exposure: yes; Ethernet Interface: 1 RJ45 10/100M self-adaptive Ethernet port; On-board Storage: Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB; Audio: 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%,
1 output (line out), line level, output impedance: 600 Ω; Alarm: 2 input(s), 1 output(s); Reset: Yes; Basic Event: Motion detection,video tampering alarm,alarm input and output,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error, abnormal restart); Smart Event: Line crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection; Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,and PTZ actions (such as preset, patrol scan, pattern scan),audible warning,white light flashing; Smart Tracking: Manual tracking,auto-tracking; Smart Linkage: panorama linkage, tracking takeover, track in turn; Face Capture: Support detecting up to 5 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face; Regional People Counting: Yes; Power: 24 VAC, Max. 60 W, Hi-PoE; Dimension: Ø222.3 mm × 387.2 mm (Ø8.75″ × 15.2″); : Approx. 6 kg (13.23 lb.); Material: ADC12,Plastic,PC+10%GF; Operating Condition: -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing); General Function: mirror,watermark,password protection,IP address filter; Demist: Yes; Protection: IP66 (IEC 60529-2013)
