Hikvision Thermal & Optical Bi-Spectrum Network Turret Camera HM-TD1218-7/G0/T1A

Specifications

Image Sensor: Vanadium Oxide Uncooled Focal Plane Arrays; Resolution: 160 × 120; Pixel Pitch: 12 μm; Spectral Range: 8 μm to 14 μm; NETD: ≤25 mK (25°C, F1.0); Focal Length: 6.9 mm; IFOV: 1.74mrad; Field of View: 24.9° × 18.7° (H × V); Min. Focusing Distance: 1.3 m; Aperture: F1.0; Digital Zoom: ×2, ×4; Image Sensor: 1/2.7″ Progressive Scan CMOS; Resolution: 5MP, 2688 × 1944; Min. Illumination: 0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR; Shutter Speed: 1 s to 1/100,000 s; Focal Length: 8 mm; Field of View: 39.4°(H) x21.96°(V); Aperture (Range): F1.6; WDR: 120 dB; Bi-spectrum Image Fusion: Display the details of optical channel on thermal channel; Picture in Picture: Display partial image of thermal channel on the full screen of optical channel; Target Coloration: Yes. Supported in white hot and black hot mode.; Light Supplement: Hybrid (IR, White light or Smart mode); IR Distance: Up to 60m; White Light Range: Up to 60 m; Visual Alarm: Yes. White light alarm with adjustable flashing frequencies; Audio alarm: Yes, for two types of audible alarm (VCA and Temperature Exception)
2 preset voice alerts (one for each)
6 importable user-defined voice alerts (6 options shared in the two types); VCA: 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total.; Temperature Measurement: 3 temperature measurement rule types (point, area, line), 21 rules in total; Temperature Range: -20 °C to 150 °C (-4 °F to 302 °F); Temperature Accuracy: ±8°C (±14.4°F); Fire Detection: Dynamic fire detection, up to 10 fire points detectable; Main Stream: Thermal:
25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (2688 × 1944, 2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1944, 2688 × 1520, 1920 × 1080, 1280 × 720); Sub-stream: Thermal:
25 fps (704 × 576, 640 × 512, 320 × 240)
Optical:
50 Hz: 25 fps (704 × 576, 352 × 288)
60 Hz: 30 fps (704 × 480, 352 × 240); Video Compression: Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG; Audio Compression: G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM; Color Palettes: 17 types (White hot, Black hot, Fusion 1, Rainbow, Fusion 2, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice fire, Rain, Red hot, Green hot, Dark blue, Winter, Summer); Protocols: IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP; Network Storage: MicroSD/SDHC/SDXC card (up to 512 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR); API: ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G, Profile T, Profile M),OTAP; Simultaneous Live View: Up to 20 channels; User/Host level: Up to 32 users, 3 levels: Administrator, Operator, User; Security: User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering; Client: iVMS-4200, Hik-Connect; Web Browser: Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0+, Firefox 52.0 +; Alarm Input: 1, alarm input (0-5 VDC); Alarm Output: 2, alarm output (alarm response actions configurable); Alarm Action: SD recording/Relay output/Smart capture/FTP upload/Email linkage; Audio Input: 1, 3.5 mm Mic in/Line in interface
Line input: 2 – 2.4 V [p-p], output impedance: 1 KΩ ± 10%; Audio Output: Linear level, impedance: 600 Ω; Communication Interface: 1, RJ45 10 M/100 M Self-adaptive Ethernet interface.
1, RS-485 interface (half duplex); Web Client Language: 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil); Power Supply: 12 VDC ± 25%, φ 5.5 mm coaxial power plug
PoE (802.3at, class 4); Power Consumption: 12 VDC ± 25%: 1.1A to 1.8 A, Max 16 W
PoE (802.3af, class 3): 42.5 V to 57 V, 0.4 A to 0.3 A, Max 17W; Working Temperature/Humidity: Temperature: -40°C to 65°C (-40°F to 149°F)
Humidity: 95% or less; Protection Level: IP67 Standard
TVS 6000V lightning protection, surge protection, voltage transient protection; Dimensions: 138.3 mm × 138.3 mm × 121.6 mm; : 975.6 g; VCA Range for Humans: 70 m; VCA Range for Vehicles: 210 m; EMC: CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN50130-4: 2011+A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC (ICES-003: Issue 7)
KC (KSC9832: 2019; KSC9835: 2019); Safety: CB: IEC 62368-1: 2014+A11;
CE-LVD: EN 62368-1: 2014/A11: 2017;
BIS: IS 13252 (Part 1): 2010/ IEC 60950-1: 2005
LOA: SANS/IEC 60950-1; Environment: CE-RoHS：2011/65/EU,
WEEE: 2012/19/EU,
Reach：Regulation(EC) No 1907/2006; Protection: IP67: IEC 60529-2013
