Optimize your office or commercial space with the MikroTik cAP ax. This powerful Wi-Fi 6 ceiling access point is available at Beyond Innovate. It is designed for seamless integration and superior performance in crowded environments. The cAP ax delivers fast, stable, and secure wireless connectivity.
The cAP ax leverages the latest Generation 6 (802.11ax) wireless standard. It provides up to 90% higher speeds in the 2.4 GHz spectrum (574 Mbps). Moreover, it offers up to 40% higher speeds in the 5 GHz spectrum (1200 Mbps). This surpasses previous generations. It ensures exceptional performance even with numerous connected devices, thanks to features like OFDMA and BSS Coloring.
A modern quad-core 1.8 GHz CPU and 1GB of RAM equip the cAP ax. Thus, it handles complex network configurations with ease. It runs MikroTik’s feature-rich RouterOS v7. This offers advanced features. These include IPsec hardware encryption, Wireguard, BGP, and comprehensive firewall rules. Its discreet ceiling-mount design also helps prevent signal loss from obstacles. It blends seamlessly into any interior.
Installation and maintenance are simplified with PoE-in and PoE-out capabilities. This allows the cAP ax to power other devices. Examples include CCTV cameras or additional access points. Furthermore, centralized management is effortless. MikroTik’s CAPsMAN system enables easy setup and control of hundreds of cAP ax devices.
Specifications
{
“Specifications – Product code”: “cAPGi-5HaxD2HaxD”,
“Specifications – Architecture”: “ARM 64bit”,
“Specifications – CPU”: “IPQ-6010”,
“Specifications – CPU core count”: “4”,
“Specifications – CPU nominal frequency”: “auto (864 – 1800) MHz”,
“Specifications – Switch chip model”: “IPQ-6010”,
“Specifications – RouterOS license”: “4”,
“Specifications – Operating System”: “RouterOS v7”,
“Specifications – Size of RAM”: “1 GB”,
“Specifications – Storage size”: “128 MB”,
“Specifications – Storage type”: “NAND”,
“Specifications – MTBF”: “Approximately 200’000 hours at 25C”,
“Specifications – Tested ambient temperature”: “-40°C to 70°C”,
“Specifications – IPsec hardware acceleration”: “Yes”,
“Specifications – Suggested price”: “$129.00”,
“Wireless capabilities – Wireless 2.4 GHz Max data rate”: “574 Mbit/s”,
“Wireless capabilities – Wireless 2.4 GHz number of chains”: “2”,
“Wireless capabilities – Wireless 2.4 GHz standards”: “802.11b/g/n/ax”,
“Wireless capabilities – Antenna gain dBi for 2.4 GHz”: “6”,
“Wireless capabilities – Wireless 2.4 GHz chip model”: “QCN-5022”,
“Wireless capabilities – Wireless 2.4 GHz generation”: “Wi-Fi 6”,
“Wireless capabilities – Wireless 5 GHz Max data rate”: “1200 Mbit/s”,
“Wireless capabilities – Wireless 5 GHz number of chains”: “2”,
“Wireless capabilities – Wireless 5 GHz standards”: “802.11a/n/ac/ax”,
“Wireless capabilities – Antenna gain dBi for 5 GHz”: “5.5”,
“Wireless capabilities – Wireless 5 GHz chip model”: “QCN-5052”,
“Wireless capabilities – Wireless 5 GHz generation”: “Wi-Fi 6”,
“Wireless capabilities – WiFi speed”: “AX1800”,
“Ethernet – 10/100/1000 Ethernet ports”: “2”,
“Ethernet – Number of 1G Ethernet ports with PoE-out”: “1”,
“Powering – Number of DC inputs”: “2 (PoE-IN, DC jack)”,
“Powering – DC jack input Voltage”: “18-57 V”,
“Powering – Max power consumption”: “36 W”,
“Powering – Max power consumption without attachments”: “11 W”,
“Powering – Cooling type”: “Passive”,
“Powering – PoE in”: “802.3af/at”,
“Powering – PoE in input Voltage”: “18-57 V”,
“PoE-out – PoE-out ports”: “Ether2”,
“PoE-out – PoE out”: “Passive PoE up to 57V”,
“PoE-out – Max out per port output (input 18-30 V)”: “600 mA”,
“PoE-out – Max out per port output (input 30-57 V)”: “400 mA”,
“PoE-out – Max total out (A)”: “600 mA”,
“PoE-out – Total output power”: “19.2”,
“Certification & Approvals – Certification”: “CE, FCC, IC, EAC, ROHS”,
“Certification & Approvals – IP”: “20”,
“Other – CPU temperature monitor”: “Yes”,
“Other – Mode button”: “Yes”,
“Wireless specifications – 1MBit/s”: “23”,
“Wireless specifications – 11MBit/s”: “23”,
“Wireless specifications – 6MBit/s”: “24”,
“Wireless specifications – 54MBit/s”: “21”,
“Wireless specifications – MCS0”: “24”,
“Wireless specifications – MCS7”: “20”,
“Wireless specifications – MCS9”: “19”,
“Wireless specifications – MCS11”: “17”
}
