Experience reliable and affordable dual-band Wi-Fi with the MikroTik hAP ac lite, a versatile access point perfect for homes and small offices, available at Beyond Innovate. This compact device offers simultaneous Wi-Fi coverage on both 2.4 GHz and 5 GHz frequencies.
The hAP ac lite supports 802.11b/g/n on 2.4 GHz (dual-chain, up to 300 Mbps) and 802.11a/n/ac on 5 GHz (single-chain, up to 433 Mbps), delivering combined AC750 speeds. Its integrated antennas (1.5 dBi for 2.4 GHz, 2 dBi for 5 GHz) provide 360-degree coverage, ensuring a consistent wireless experience throughout your space.
Under the hood, the device is powered by a 650MHz CPU and 64MB of RAM, efficiently handling everyday networking tasks. It features five 10/100 Mbps Ethernet ports for wired connections, and notably, offers passive PoE output on port 5.
Specifications
{
“Specifications – Product code”: “RB952Ui-5ac2nD”,
“Specifications – Architecture”: “MIPSBE”,
“Specifications – CPU”: “QCA9531”,
“Specifications – CPU core count”: “1”,
“Specifications – CPU nominal frequency”: “650 MHz”,
“Specifications – Switch chip model”: “QCA9531”,
“Specifications – Dimensions”: “113 x 89 x 28mm”,
“Specifications – RouterOS license”: “4”,
“Specifications – Operating System”: “RouterOS”,
“Specifications – Size of RAM”: “64 MB”,
“Specifications – Storage size”: “16 MB”,
“Specifications – Storage type”: “FLASH”,
“Specifications – MTBF”: “Approximately 100’000 hours at 25C”,
“Specifications – Tested ambient temperature”: “-30°C to 70°C”,
“Specifications – Suggested price”: “$59.00”,
“Wireless capabilities – Wireless 2.4 GHz Max data rate”: “300 Mbit/s”,
“Wireless capabilities – Wireless 2.4 GHz number of chains”: “2”,
“Wireless capabilities – Wireless 2.4 GHz standards”: “802.11b/g/n”,
“Wireless capabilities – Antenna gain dBi for 2.4 GHz”: “1.5”,
“Wireless capabilities – Wireless 2.4 GHz chip model”: “QCA9531”,
“Wireless capabilities – Wireless 2.4 GHz generation”: “Wi-Fi 4”,
“Wireless capabilities – Wireless 5 GHz Max data rate”: “433 Mbit/s”,
“Wireless capabilities – Wireless 5 GHz number of chains”: “1”,
“Wireless capabilities – Wireless 5 GHz standards”: “802.11a/n/ac”,
“Wireless capabilities – Antenna gain dBi for 5 GHz”: “2”,
“Wireless capabilities – Wireless 5 GHz chip model”: “QCA9887”,
“Wireless capabilities – Wireless 5 GHz generation”: “Wi-Fi 5”,
“Wireless capabilities – WiFi speed”: “AC750”,
“Ethernet – 10/100 Ethernet ports”: “5”,
“Peripherals – Number of USB ports”: “1”,
“Peripherals – USB Power Reset”: “Yes”,
“Peripherals – USB slot type”: “USB type A”,
“Peripherals – Max USB current (A)”: “1”,
“Powering – Number of DC inputs”: “2 (PoE-IN, DC jack)”,
“Powering – DC jack input Voltage”: “10-28 V”,
“Powering – Max power consumption”: “20 W”,
“Powering – Max power consumption without attachments”: “8 W”,
“Powering – Cooling type”: “Passive”,
“Powering – PoE in”: “Passive PoE”,
“Powering – PoE in input Voltage”: “10-28 V”,
“PoE-out – PoE-out ports”: “Ether5”,
“PoE-out – PoE out”: “Passive PoE”,
“PoE-out – Max out per port output (input 18-30 V)”: “500 mA”,
“PoE-out – Max total out (A)”: “500 mA”,
“Certification & Approvals – Certification”: “CE, FCC, IC, EAC, ROHS”,
“Certification & Approvals – IP”: “IP20”,
“Wireless specifications – 1MBit/s”: “22”,
“Wireless specifications – 11MBit/s”: “22”,
“Wireless specifications – 6MBit/s”: “23”,
“Wireless specifications – 54MBit/s”: “20”,
“Wireless specifications – MCS0”: “23”,
“Wireless specifications – MCS7”: “19”,
“Wireless specifications – MCS9”: “16”
}
