The MikroTik S+RJ10 is a versatile SFP+ module. It enables high-speed connectivity over standard twisted-pair cables. This module offers speeds up to 10 Gbps. It transforms SFP+ ports into RJ45 copper ports.
This unique module supports various data rates. These include 10M, 100M, 1G, 2.5G, 5G, and 10G. It is ideal for upgrading existing networks. You can achieve 10 Gbps without installing new fiber. The S+RJ10 is compatible with any MikroTik device. Devices with SFP+ ports can utilize it. Active cooling is recommended for optimal performance. Passive cooling devices may require extra cooling.
The latest revision, S+RJ10 /r2, brings improvements. It supports Jumbo frames up to 10218 Bytes. Link speed reporting is now accurate. DDM monitoring for voltage and temperature is also supported. The module is based on the Marvell 88X3310P chip. Power consumption is low, at 2.4W maximum for a 30m 10GBASE-T link. It can transmit 10 Gbps up to 30 meters over Cat6a/Cat7 cables. For longer distances, up to 200m, speeds may vary. This module offers a cost-effective solution. It allows using existing copper infrastructure for 10 Gigabit Ethernet.
